How to Identify a RELAB part number?
Nozzles are the last part that the water touches on it’s way out of the pipe. Although the spray nozzle is a small simple component, that controls how much pressure and water flow is produced.
It is very important to choose a correct nozzle, first you need to know how to read the part number/ordering number.
1. Part Number: FD10/24-SS304+CE2, Mist Nozzle
Model type: FD series High Pressure Mist Nozzle
Connection thread size: 10-24UNC-2A (external thread, with o-ring)
Body material: 304 stainless steel
Spray orifice size: 0.2mm ceramic orifice
Description: 10/24unc-2A thread FD series high pressure mist nozzle with 3.2 lph and 60 degree spray angle @60 bar in 304 stainless steel body and .2mm ceramic orifice insert.
2. Part Number: FG1/8-SS316+CE2, Mist Nozzle
Model type: FG series High Pressure Mist Nozzle
Connection thread size: 1/8 BSPP male (parallel thread, with o-ring)
Body material: 316 stainless steel
Spray orifice size: 0.2mm ceramic orifice
Description: 1/8 BSPP male thread FG series high pressure mist nozzle with 3.1 lph and 65 degree spray angle @60 bar in 316 stainless steel body and .2mm ceramic orifice insert.
3. Part Number: BB1/4-SS 10, Standard Full Cone Nozzle
Model type: BB series Standard Full Cone Nozzle
Connection thread size: 1/4 male BSPT
Full material: 303 stainless steel
Capacity code: #10
Description: 1/4 BSPT male thread BB series standard full cone nozzle with 6.4 lpm and 65 degree spray angle @2 bar in 303 full stainless steel material.
4. Part Number: CB1/8N-6501, Flat Fan Nozzle
Model type: CB series standard Flat Fan Nozzle
Connection thread size: 1/8 NPT male
Body material: brass
Capacity code: #6501
Description: 1/8 NPT male thread CB series small-capacity flat fan nozzle with 0.39 lpm and 65 degree spray angle @3 bar in full brass material.
BB Full Cone Nozzle
Model BB is the most commonly used full cone nozzle. It has a built-in X-style vane, which can better reduce clogging. If you want fast delivery, BB nozzle is the best choice.
Read MoreCB Small-flow Flat Fan Nozzle
Model CB is a small flow flat fan nozzle with a T-shaped design to be more convenient and accurate arrangement and better spray effect. The coverage area overlaps by 30% to obtain complementary and more uniform distribution.
Read MoreFD Cleanable Ceramic Mist Nozzle
Model FD is a common high pressure mist nozzle. Its open pressure is 20 bar due to an internal anti-drip valve. Model FD-CE is a ceramic orifice nozzle without the filter. The construction is the same as FD-SS model, except for the orifice.
Read MoreFG 316SS Ceramic Fog Nozzle
Compared to the FD, FE and FF series, the FG model has a larger ceramic spray disc and SS316 body. Ceramic material has a higher finish than stainless steel, and the liquid has a stronger pass rate at the same pressure.
